economy fuel saver black oil flooded black oil fuel saver burn water-in-black oil fuel emulsion

the most effective both simple technical decision and the device
for black oil economy, for burning black oil with water and not standard heavy black oil.
Installation for 1 hour, does not vary a regime card of a boiler

Water-black oil emulsions production

During the cavitation processing, black oil (mazut) is transforming into homogeneous suspension, with completely mixed all light and heavy (bitumen) fractions, and also water and solid particles. That improves the atomizing burners functioning: reducing of nozzles clogging, forming of uniform and stable (without fluctuations) flame cone with decreasing of soot build-up. Burners, in case of load reduce, are working steady. The negative influence of water contained in black oil is minimizing. During the combustion process, it is possible to replace the black oil with water-black oil emulsion (with water content up to 15%) for saving about 10% of black oil without any deterioration of boilers technological parameters. It is possible to replace the expensive sorts of black oil with low-grade ones with keeping of all main physical and chemical properties of fuel in water-black oil emulsions (combustion heat, viscosity, etc.)

The replacement of black oil with high-quality water-black oil emulsion with further combustion in power boilers is providing the possibility of:

• Increasing of heat boiler efficiency for 1-2%;
• Decreasing the blowout of harmful matters to atmosphere (for example, decreasing of CO and soot - two times, NOx – 30-50%, SO2 – 30-70%);
• 1,5-2 decreasing of soot build-up on heat exchanger surface in a boiler;
• Decreasing of high temperature fuel heating before the burning;
• Reducing of fuel consumption rate for 5-11%;
• Avoiding the bottom water output with their entering into emulsion.

The list of the effects connected with use for burning water-black oil emulsions	Possible economy of burnt fuel
Transformation of water which contains in black oil in finely divided condition by emulsification	up to 2%
Decrease excess-air coefficient in boiler furnace on 0,1	up to 0,7%
Decrease in temperature of leaving gases on 10°С	up to 0,6%
Heating of a feedwater in water waste-gas heater on 10°С	up to 1,6%
Decrease in temperature of a feedwater on an input in water waste-gas heater on 10°С	up 0,24%
Decrease in ejection of sootflake	up to 0,2%
Keeping of cleanliness boiler heat-exchange apparatus (surfaces)	up to 2%
Reduction of temperature of heating of black oil on 30°С	up to 1%
Opportunity of replacement of steam dispersion atomizers on simply mechanical atomizers	up to 1%
Keeping up of nominal EFFICIENCY of a thermal boiler in a mode 75 % from nominal	up to 0,7%
Decrease in losses of fuel on evaporation of water containing in structure of black oil	up to 0,8%
Possible total economy of fuel	up to 10 %

Some TRGA models can be installed directly in black oil supply to nozzles line, but also can be used for long-term storage tanks filling. Suspension structure is preserving its parameters for more than a half year, with avoiding of layers build-up in tanks, significant deposits volume reducing and uniform water distribution through the all emulsion volume. Such black oil has a less viscosity, with consequent significant facilitation of its transporting through pipelines.

design feature - small weight, the high efficiency, not littered, with a greater resource of the work, not demanding additional power supplies and practically not loading regular pump, universal (at replacement of internal parts) for black oil, diesel and other fuel. Maximal reliability and durability in operation.

4 different designs and 8 updatings for individual selection under a wide spectrum of technical projects are used.

homogenizers TRGA-40 and TRGA-10 (adjustable) - can be made for any productivity, and can be adjusted for change its productivity and a mode of processing (cavitational or turbulent) depending on purpose of use. this effect does not provide any similar unit.

homogenizers TRGA-2F and TRGA-3 (noncontrollable) - can be made for any productivity and do not comprise omentums and sealants, that allows to use one with aggressive kinds of fuel

weight TRGA from 5 up to 50 kg, productivity from 5 up to 50 tons per 1 hour. We can make homogenizers or emulsifier on any productivity. Working temperature from 40 up to 200 degree centigrade. Processing of black oil is made without addition any reagents or additives. Activator TRGA is not magnetic or catalysts system.

General efficiency and durability of the boiler equipment increases by the termination of pollution of surfaces of heating by soot and coke and elimination of old adjournment.

Using TRGA activator changes physical and chemical properties of black oil
- decreases density of black oil
- increases fluidity of black oil
- decreases the temperature of freezing
- changes the fractional structure which reduces temperature of flash

The additional effect - is provided destruction of cindery particles in black oil which litter atomizers

the reached effects - economy of fuel of 10 %, decrease in a smoke, toxicity the economic return nearly 2 months, power consumption of 0.5-1 kW/h on 1 tonn

advantages - the most competitive price, the degree of dispersiveness is similar with rotor emulsifiers (the test - black oil with 20% of water is not stratified more than 200 days). It is mounted by the mechanic of average qualification in current of hour. Economy on starting-up and adjustment works. Significant economy of transport charges.

TRGA, mixing black oil with water, save from 50 up to 500 dollars per hour

homogenizer - TRGA (2007-2008)

devices for economy of black oil

manufacture and burning of water-fuel mixes and water-in- black oil emulsion

TRGA-10

emulsifier homogenizer jet hydrodynamical cavitation device

TRGA-3R

TRGA-3

Stable water-fuel mixes and water-in-black oil emulsion which is prepared on emulsifier TRGA without additional chemical additives.

Photo, properties, time of stability

The scheme of installation emulsifier TRGA for manufacture stable water-fuel mixes and water-in-black oil emulsion

водномазутные смеси обработка обводненного мазута

Result of use of the activator for black oil economy TRGA-3 which has been mounted before atomizers of a boiler in Croatia

Photo and ecological tests

Result of use of the activator for black oil TRGA-3 and emulsifier TRGA-10 in Serbia.

Schemes of preparation of fuel, photos, films " burning usual black oil " and " burning water-in-black oil emulsion "

economy black oil, diesel, boiler and oven fuel

Use technologies emulsifier + activator for creation and burning water-fuel mixes and water-in- black oil emulsion together with water which contains waste or pollution

(water with the rests of oil, water with the rests of oil, water from the water drain, water from meat-packing plants and factories on manufacture of oil and margarine...)

The difference between

" burning usual black oil "
and
" burning water-in-black oil emulsion "

Why model TRGA the best in the class, please compare
